Trench MOS

Part Number	Download	Circuit	Status	Type	Process	ESD Yes/No	VDS V	VGS V	ID A	VGS(TH) V	RDS(mΩ)@VGS 10V Typ	RDS(mΩ)@VGS 10V Max	RDS(mΩ)@VGS 4.5V Typ	RDS(mΩ)@VGS 4.5V Max	Package
Reset Reset All			Active OK Reset	Dual-N Dual-P N/P-ch Single-N Single-P OK Reset	Trench OK Reset	No Yes OK Reset	OK Reset	±10 ±12 ±16 ±20 ±25 ±30 ±6 ±7 ±8 OK Reset	OK Reset	-0.35~-1.1 -0.3~-1.0 -0.45~ -0.45~-1.0 -0.45~-1.2 -0.4~-0.9 -0.4~-1.0 -0.4~-1.2 -0.4~-1.3 -0.4·-1.0 -0.55~-1.0 -0.5~-0.9 -0.5~-1.0 -0.5~-1.5 -0.6~-1.5 -0.7~-1.3 -0.7~-1.4 -0.9~-2.0 -1.0~-2.0 -1.0~-2.5 -1.0~-3.0 -1.0~2.5 -1.1~-2.2 -1.2~-2.2 -1.5~-2.5 -1.5~-3.5 -2.0~-4.0 0.35~1.0 0.35~1.1 0.35~1.4 0.3~1.1 0.45~1.0 0.45~1.1 0.45~1.2 0.4~1.0 0.4~1.1 0.4~1.2 0.4~1.4 0.5~0.9 0.5~1.0 0.5~1.1 0.5~1.2 0.5~1.3 0.5~1.5 0.5~2.0 0.65~1.2 0.6~1.0 0.6~1.2 0.6~1.4 0.6~1.5 0.7~1.4 0.7~1.5 0.8~1.5 0.8~3.0 0.9~1.5 1.0~2.0 1.0~2.2 1.0~2.5 1.0~3.0 1.2~2.5 1.2~2.8 1.2~3.0 1.3~2.3 1.3~2.5 1.5~2.5 2.0~4.0 3.0~5.0 OK Reset	OK Reset	OK Reset	OK Reset	OK Reset	CSPB1111-4 CSPB1212-4 CSPB1313-4 CSPB1515-4 CSPB1717-4 CSPB1912-6 CSPB2217-6 CSPC2019-10 CSPC2115-10 CSPC2623-10 CSPC2624-10 CSPC3015-10 CSPC3028-14 CSPC3030-14 CSPC3220-10 CSPC3421-10 DFN1006-3L DFN1006-3L-A DFNWB2x2-6L DFNWB2x3-6L DFNWB3x3-8L DFNWB5x2-6L PDFNWB3.3x3.3-8L PDFNWB3.3x3.3-8L-B PDFNWB5x6-8L PDFNWB5x6-8L-A SOP8 SOT-223 SOT-23 SOT-23-3L SOT-23-6L SOT-323 SOT-363 SOT-523 SOT-563 SOT-723 SOT-89-3L TO-220-3L-C TO-252-2L TO-263-2L-B TO-3PN TO-92 TSSOP8 WBFBP-03E OK Reset

CJL2016			Active	Dual-N	Trench	No	20	±10	6	0.45~1.2	-	-	15.7	20	SOT-23-6L
CJL2019			Active	Dual-N	Trench	No	20	±10	5	0.45~1.2	-	-	19.5	27	SOT-23-6L
CJL8810			Active	Dual-N	Trench	Yes	20	±12	7	0.4~1.0	13.5	20	14.5	22	SOT-23-6L
CJL8820			Active	Dual-N	Trench	Yes	20	±12	7	0.5~1.1	15	21	17	24	SOT-23-6L
CJX3134K			Active	Dual-N	Trench	Yes	20	±12	0.75	0.35~1.1	-	-	270	380	SOT-563
CJS2016			Active	Dual-N	Trench	No	20	±10	6	0.45~1.2	-	-	15.7	20	TSSOP8
CJS2019			Active	Dual-N	Trench	No	20	±10	5	0.45~1.2	-	-	19.5	27	TSSOP8
CJS8804			Active	Dual-N	Trench	Yes	20	±12	8	0.5~1.0	9.8	13	10.5	14	TSSOP8
CJS8810			Active	Dual-N	Trench	Yes
